Technical Characteristics

HL-300pro Battery Powered Crimping Tool provides maximum efficiency when used for high-volume dedicated cutting or crimping applications. All tools also come with two batteries, 12 sets of crimping dies, a shoulder strap, a charger, and a carrying case. It is a tool for crimping Cu/Al lugs with cables from 10-300mm². It is powered by Li-ion, actuated by a motor, and controlled by an MCU. With a high-pressure hydraulic system, it is a perfect tool to be used in the electrical construction field.

1. 360° flip-top latch crimping head, working at any site
2. Pistol-type tool body design for better balance and easy handing
3. Double Piston pump and powerful motor ensure quick crimp
4. Automatically fully retract ram and stop the motor when complete crimp
5. Manually retract the ram in case of need
6. LED illuminate work area & low battery charges or lacking pressure, an acoustic signal sounds and LED flash
7. Li-ion battery with high capacity and requires short charging time
8. A temperature sensor makes the tool stop working automatically when the temperature over 60° under a long time working

Specifications

Model: HL-300pro Battery Powered Crimping Tool
Max. crimping force: 60KN
Crimping range: 10-300 mm2
Stroke: 17mm
Hydraulic oil: Shell Tellus T15#
Ambient temperature: -10 - 40℃
Battery: 18v 5.0Ah Li-Ion
Crimping cycle: 3s-6s(depending on the connector size)
Crimp/charger: Approx. 260 crimps (Cu150 mm2)
Charging voltage: AC 100V〜240V; 50〜60Hz
Charging time: Approx. 2 hours
OLED display: display voltage, temperature, crimping times, errors information
Accessories:
Crimping die (mm2): 10.16.25.35.50.70.95.120.150.185.240.300
Battery: 2 pcs
Charger: 1 pcs
Sealing ring of cylinder: 1 set
Sealing ring of safety valve: 1 set
