Custom HL-85B Double Piston Pump Battery Powered Cable Cutter

WENZHOU HEWLEE  TOOLS CO., LTD. Home / Products / Electrical Tool / Cable Cutter / Battery Cable Cutter / HL-85B Double Piston Pump Battery Powered Cable Cutter

Technical Characteristics

HL-85B for cutting Cu/Al cable and armored cable. The unit is equipped with a double piston pump which is characterised by a rapid approach of the dies forward the connector and a slow crimping motion. This machine is used to steel bar(steel rod) rebar straight and cutting. It’s convenient to put in construction sites and steel bar processing sites. Best quality Reinforced enclosure, compact structure, movable wheels, low power loss. High hardness blade base and connection rod, using a high-speed standard motor, high quality and steady performance, long service life. All gear shafts are produced by our own CNC processing center, make sure high accuracy of size and excellent quality. The machine is extra thick and hard, high quality can work on heavy duty.

1. The head has an open and rotated design

2. Double sections hydraulic system, release pressure automatic

3. Use high capacity and good performance 18V battery

4. Packaged in a thick box

5. The lightest battery hydraulic cutter in this field.

6. To be operated with a single hand in an optional direction.

7. It's applicable for operation on overhead lines and common urgent maintenance.

8. The advance speed for the position could be stepless speed adjusted.

9. Mechanical automatic pressure release. when the battery is exhausted, the piston could be easily retracted and tool from hurting and damaging.

10. With safety valve. when cutting under overload. it could be automatically pressure released to protect the operator and tool from hurting and damaging.

11. Cutting is prohibited when the conductor is on tension.

12. Unique, quick, light head open design for more convenient operation. It's applicable for cutting overhead cable in 45mm or other copper, alloy conductor. The blade is made from specific heart-treated steel for a much longer shelf life.

13. The head could be rotated 360 degrees for proper operating position.

Specifications

Model

HL-85B Battery powered Cutting Tools

Cutting range:

Φ85mm Cu/Al cable
Cutting force: 120KN

Stroke:

45mm
Cutting cycle: 10s-30s(depend on the size)

Battery voltage:

18V /5.0Ah Li-Ion

Charging time:

Approx 1.5 hours
Weight(incl. battery): Approx. 8.8kg

Gross weight:

Approx.15kg

Carton size:

540x430x170mm

Package:

One pc/Aluminum alloy case/Cardboard box
Product standard: 1pcs of tool, 2pcs of Li-Ion battery, 1pcs of charger, 1pcs of plastic case, 1pcs of straps, 1pcs of manual
